OUTLAW® 110
ELECTRONIC FUEL INJECTED (EFI) 110 CC ENGINE
EFI for consistent starting, improved idle quality, and a crisp linear throttle response.
PARENT ADJUSTABLE SPEED LIMITING
Easily select from a 15 MPH restricted mode, or unrestricted 29 MPH based on rider skill level. EFI provides more accurate speed control in all operating condition when compared to a mechanical throttle limiter.
STANDARD SAFETY FEATURES
Daytime running lights, and a safety whip flag as standard equipment.
LONG-TRAVEL FRONT AND REAR SUSPENSION
Bumps in the yard and on the trail are soaked up by 5" of suspension travel up front and 6" of travel in the back.
ELECTRIC START
Straightforward starting makes it easier to hit the trail.
SUITABLE FOR AGES 10 AND OVER
This vehicle is for recreational use by young operators 10 and older while under adult supervision.
ENGINE & DRIVETRAIN
| Engine Type | 4-Stroke Single Cylinder |
| Cylinders-Displacement (cc) | 112 cc |
| Fuel System | Electronic Fuel Injection |
| Transmission/Final Drive | Automatic PVT F/N/R; O-ring Chain |
| Drive System Type | 2WD |
| Cooling | Air |
Suspension
| Front Suspension | Single A-Arm with 12.7 cm Travel |
| Rear Suspension | Single A-Arm with 12.7 cm Travel |
Brakes
| Front/Rear Brakes | 4-Wheel Drum |
| Parking Brake | Lockable Hand Lever |
Tyres / Wheels
| Front Tyres | 19 x 7-8 Duro |
| Rear Tyres | 18 x 9.5-8 Duro |
| Wheels | Stamped Steel |
DIMENSIONS
| Bed Box Dimensions (L x W x H) | N/A |
| Front/Rear Rack or Box Capacity | N/A |
| Fuel Capacity | 5.9 L |
| Ground Clearance | 10.2 cm |
| Overall Vehicle Size (L x W x H) | 155,6 x 93.3 x 97.8 cm |
| Wheelbase | 105.4 cm |
| Estimated Dry Weight | 126 kg |
Features
| Cargo System | |
| Hitch Towing Rating | |
| Hitch/Type | |
| Instrumentation | N/R Light |
| Variants | Off-road |
