Home / All Off Road Vehicles /RANGER® / RANGER DIESEL HD EPS ADC

RANGER DIESEL HD EPS ADC

polaris-ranger-diesel-hd-eps-adc

Polaris RANGER DIESEL HD EPS ADC for Sale at Ultimate Polaris Springwood in Slacks Creek, QLD | Specifications and Review Information

TRIM & COLOUR OPTIONS

RANGER DIESEL HD EPS ADC

RANGER DIESEL HD EPS ADC

The definition of RANGER tough with Active Decent Control (ADC) and HD Features, including upgraded rear driveshaft, grease nipples, HD sway bar, sealed suspensions bushings, sealed ball joints, driveshaft spline seals and hand brake.

  • Sealed bearings and bushings
  • Heavy-duty steering rack
  • 2-piece sealed CV drive shaft
  • Mud Guards
  • Easy-Access Radiator Panel
  • Tough, One-Piece Chassis



A WHOLE NEW KIND OF RANGER TOUGH

33 cm Ground Clearance. 27" Tyres. 27.9 cm Usable Travel. The RANGER Diesel is tougher and more reliable than ever.



RANGER DIESEL HD EPS ADC






RANGER DIESEL FEATURES

Feature

PERFORMANCE

  • 140 Amps Charging System
  • 65 kmph Top Speed
  • 1134 kg Towing Capacity
  • 720 kg Payload Capacity
  • 2.5 cm DEEPER BOX
  • 43.5 L
  • True On-Demand AWD
  • EPS, EBS, ADC
Features

REFINEMENT

  • Digital Gauge
  • Thicker Seat Cushioning - Added 2.5 cm of padding
  • More Leg Room for Getting In/Out
  • 17% More Storage - 2 Glove Boxes and 6 Cup Holders
  • Flip-Up Passenger Seat
Feature

A WHOLE NEW KIND OF RANGER TOUGH

33 cm Ground Clearance. 27" Tyres. 27.9 cm Usable Travel. The RANGER Diesel is tougher and more reliable than ever.



Disclaimer: Warning - Models could be shown with optional extra accessories.

ENGINE & DRIVETRAIN

Engine Type Kubota 3-Cylinder Diesel
Cylinders-Displacement (cc) 898 cc / 24.8 HP
Fuel System Mechanical Injection
Transmission/Final Drive Automatic PVT H/L/N/R/P; Shaft
Drive System Type On-Demand True AWD / 2WD / Versatrac Turf Mode. Active Decent Control (ADC) and HD features including upgraded rear driveshaft, grease nipples, HD sway bar, sealed suspensions bushings, sealed ball joints and driveshaft spline seals.
Cooling Liquid

Suspension / Brakes / Wheels

Front Suspension Dual A-Arm with stabilizer bar 27.9 CM travel
Rear Suspension Dual A-Arm IRS with stabilizer bar 27.9 cm travel
Front / Rear Brakes Hydraulic Disc
Parking Brake Hand Actuated
Front Tyres 27 x 9; R12
Rear Tyres 27 x 11; R12
Wheels 12" Steel

DIMENSIONS

Bed Box Dimensions (L x W x H) 93.3 x 137.8 x 31.75 cm
Box Capacity 435 kg
Fuel Capacity 43.5 L
Ground Clearance 33 cm
Overall Vehicle Size (L x W x H) 305 x 158 x 196 cm
Payload capacity 720 kg
Person capacity 3
Wheelbase 206 cm
Estimated Dry Weight 766 kg

Features

Cargo System Lock & Ride
Electronic Power Steering Standard
Hitch Towing Rating 1134 kg
Hitch / Type Receiver w/ ECE R55 Ball
Instrumentation All Digital Gauge, Speedometer, Odometer, Tachometer, 2 Trip Meters, Hour Meter, Gear Indicator, Fuel Gauge, Engine Temperature, Hi-Temp Light, Clock, Glow Plug Indicator, Low Oil Pressure Indicator, Seat Belt Indicator, Parking Brake Engaged Alarm, Horn, Backup Alarm
Lighting Headlights : Halogen
Variants Off-road
